DIB-PCA System

Hard-Shell Type
  • Basic model for epidural anesthesia after surgery.
  • No risk of infection due to its chemical resistant body and closed system.

50ml

Slide-Shell Type
  • Displays remaining volume with a slide shell in 5ml increments.
  • Visible drug solution infused provides feeling of relief and security to patients.
  • Slides to be smaller in size.

50ml100ml200ml

Soft-Shell Type
  • Lightweight and compact.
  • Less space and less cost for industrial waste.
  • Less space for storing.

200ml300ml


  • Drug Infusion Balloon

    We take pride in being a world leading company of pain control
    in anesthesia field. We received ninth society award from
    Japanese Society of Anesthesiologists.


  • Made In Japan

    All DIB products are manufactured in Japan.
    We provide unique and safe products from Japan to the world.


  • Visible Reservoir

    The transparent reservoir shows drug solution being infused
    into the body and gives a feeling of relief to patients.
    We received remarkable invention prize from Director General of
    the Science and Technology Agency.


  • Application to aerospace

    We developed a downsized water supply balloon which needs no electricity.
    The balloon has been applied as a water feeder of small animals
    rearing unit in the International Space Station.

Package Inserts

50mL

Hard-Shell Type
Product No. Type JAN code Max Vol.(ml) Flow Rate(ml/hr) Days to be used PCA
(ml)
Lockout Time (min) Set Qty/Box
003011 D-11 4547317154621 50 1 2 1 15 10
003001 D-1 4547317154133 50 1 2 1 30 10
003002 D-2 4547317154188 50 1 2 3 60 10
003003 D-3 4547317154348 50 2 1 3 120 10
003004 D-4 4547317154003 50 0.5 4 0.5 30 10
Slide-Shell Type
Product No. Type JAN code Max Vol.(ml) Flow Rate
(ml/hr)
Days to be used PCA
(ml)
Lockout Time (min) Set Qty/Box
004011 D-11P 4547317555831 50 1 2 1 15 10
004001 D-1P 4547317555800 50 1 2 1 30 10

100mL

Slide-Shell Type
Product No. Type JAN code Max Vol.(ml) Flow Rate
(ml/hr)
Days to be used PCA
(ml)
Lockout Time (min) Set Qty/Box
014104 D-104P 4547317553820 100 0.5 8 0.5 30 10
014111 D-111P 4547317553806 100 2 2 1 15 10
016162 D-162W 4547317556050 100 2 2 3 60 10

200mL

Slide-Shell Type
Product No. Type JAN code Max Vol.(ml) Flow Rate
(ml/hr)
Days to be used PCA
(ml)
Lockout Time (min) Set Qty/Box
016062 D-620W 4547317556074 200 2 4days 3 60 10
016032 D-320W 4547317556012 200 2 4days 3 120 10
016082 D-820W 4547317556036 200 4 2days 3 60 10
016083 D-830W 4547317556043 200 6 33hrs 3 60 10
Soft-Shell Type
Product No. Type JAN code Max Vol.(ml) Flow Rate
(ml/hr)
Days to be used PCA
(ml)
Lockout Time (min) Set Qty/Box
004341 OD-341P 4547317553172 200 1 8 1 30 10
004349 OD-349P 4547317653261 200 2 4 3 30 10
004032 OD-320P 4547317653346 200 2 4 3 120 10
004082 OD-820P 4547317653421 200 4 2 3 60 10
006062 OD-620W 4547317656231 200 2 4 3 60 10
006032 OD-320W 4547317656057 200 2 4 3 120 10
006759 OD-759W 4547317656248 200 3 2.5 3 30 10
006082 OD-820W 4547317656071 200 4 2 3 60 10
006359 OD-359W 4547317656064 200 4 2 3 30 10

300mL

Soft-Shell Type
Product No. Type JAN code Max Vol.(ml) Flow Rate
(ml/hr)
Days to be used PCA
(ml)
Lockout Time (min) Set Qty/Box
006559 OD-559W 4547317656217 300 4 3 3 30 10
006582 OD-582W 4547317656101 300 4 3 3 60 10
006578 OD-578W 4547317656118 300 4 3 5 120 10
006084 OD-840W 4547317656125 300 6 2 3 60 10
006085 OD-850W 4547317656170 300 6 2 5 30 10
